• Operating temperature: -20 °C ... + 40 °C
• Storage temperature: 40 °C ... + 60 °C
• Transport temperature: 40 °C ... + 60 °C
• Max. rated casing temperature (tc): 80 °C
• Relative humidity: 91% non-condensing
• Degree of protection: IP00
• Power and load wiring: 1.5 mm2 (single cable) 2.5 mm2 (stranded cable), 16 to 13 AWG
• Max. torque 0.5 Nm for screw terminals
• KNX bus wiring: 0.26 to 0.5 mm2 - 23 to 20 AWG
• Peeling: 5.0 6.0 mm
• Plastic casing
• Luminaire for flush-mounting or panel mounting (with supplied accessory)
• Weight: 37 g
• Dimensions (LxHxW): 53 x 61 x 29 mm

Functionality

• ON/OFF control and dimming of individual or grouped luminaires
• Fade time on and off, minimum and maximum brightness level, linear or logarithmic dimming curve settable from ETS
• Soft or instantaneous switching on and off, with settable delay
• Configuration of behaviour after power reset, bus ON/OFF, unloading via ETS
• Channels can be set by the ETS as independent, in parallel or with copy function from another channel
• Locking function, forced operation, staircase light, scenes, night, counter and logic functions for each channel, settable via ETS
• Alarm for short circuit, open load and power failure
• Auxiliary output function with status indication via KNX
• Manual operation with membrane buttons and for local ON/OFF testing of channels 1-2-3-4 also in the absence of the KNX bus: short press of the button switches the load on/off, pressing for at least 2 seconds makes the load flash every 1 s approx.
