System
|
|
Main Processor
|
Quad-core embedded processor
|
|
Operating System
|
Embedded LINUX
|
|
Audio and Video
|
|
IP Camera Input
|
8 Channel
|
|
Two-way Talk
|
1 Channel Input, 1 Channel Output, RCA
|
|
Display
|
|
Interface
|
1 HDMI, 1 VGA
|
|
Resolution
|
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
|
|
VGA: 1920×1080, 1280×1024, 1280×720
|
|
Decoding Capacity
|
2ch@4K 30fps, 8ch@1080P 30fps
|
|
Multi-screen Display
|
1/4/8/9
|
|
OSD
|
Camera title, Time, Camera lock, Motion detection, Recording
|
|
Recording
|
|
Compression
|
Smart H.265+/H.265/Smart H.264+/H.264
|
|
Resolution
|
8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
|
|
Record Rate
|
200Mbps
|
|
Bit Rate
|
16Kbps ~ 20Mbps Per Channel
|
|
Record Mode
|
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
|
|
Record Interval
|
1 ~ 120 min (default: 60 min), Pre-record:
1 ~ 30 sec, Post-record: 10 ~ 300 sec
|
|
Video Detection and Alarm
|
|
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
|
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18),
Video Loss and Tampering
|
|
Alarm input
|
4 Channel
|
|
Alarm output
|
1-Channel relay output,1-Channel 12V control
|
|
Playback and Backup
|
|
Playback
|
1/4/9
|
|
Search Mode
|
Time /Date, MD and Exact Search
(accurate to second), Smart search
|
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow Play,
Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
|
|
Backup Mode
|
USB Device/Network
|
