Name: Bathroom & Fitting Room Occupancy Sensor Milesight VS330 LoRaWAN®
Brand: Milesight
Availability: OutOfStock

Roll over image to zoom in Click on image to zoom

Wireless Transmission
Protocol	LoRaWAN®
Antenna	Internal Antenna
Frequency	CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4
Tx Power	16 dBm (868 MHz)/19 dBm (470 MHz)/22 dBm (915 MHz)
Sensitivity	-137dBm
Mode	OTAA/ABP Class A
Sensors
ToF
ToF FoV	27°
Detection Range	0.040 ~ 3.500m
Accuracy	± 2cm
Resolution	1mm
PIR
Detection Area	80°
Detection Distance	Maximum 2.5m
Others
Sensor Adjustable Angle	0°, 15°, 30°, 45°, 60°, 75°
Others
LED	1 × Status/Test Indicator
Button	1 × Power/Reset Button
Software
Power On/Off	Mobile App via NFC or Power Button
Configuration	Mobile App via NFC, Downlink
Physical Characteristics
Power Supply	3 x 4000 mAh ER18505 Li-SOCl₂ Replaceable Batteries
Battery Life*	Around 4.2 Years (SF7, EU868 & US915)
(90 users + within 7 consecutive hours per day)	Around 3.4 Years (SF10, EU868) Around 3.3 Years (SF10, US915)
Operating Temperature	-20°C ~ 60°C
Relative Humidity	0% - 95% (non-condensing)
Ingress Protection	IP30
Dimension	Ф100 x 24 mm (Ф3.94 x 0.95 in)
Housing & Color	PC+ABS (Flame Retardant), White
Weight	150g (Batteries Included)
Installation	Ceiling Mount or Wall Mount via Screws or 3M tapes
Approvals
Regulatory	CE, FCC, Telec
Environmental	RoHS

Tested under laboratory conditions and for guideline purposes only.

Bathroom & Fitting Room Occupancy Sensor Milesight VS330 LoRaWAN®

Description
